PRECAST STAIRS AND LANDINGS

Hillhouse Precast manufacture a wide variety of precast reinforced stair flights and landings. These offer many advantages:



  • Durability makes it particularly suitable for stairwells with high volume traffic.
  • Excellent acoustic properties eliminate much of the sound transfer issues associated with wooden or steel staircases.
  • Ideal for fire escape stairways
  • Maintenance free
  • Rapid installation gives early and safe access to subsequent floors



Our stair flights are manufactured on timber moulds giving a Type A finish, with associated landings manufactured on steel moulds giving the same Type A finish.



Our stair flight – landing connection detail is a standard nib detail. Steel angles can also be cast in to our stair flights and landings if necessary to provide an alternative bearing detail.



Landings can either be provided as separate units or can be manufactured as part of the stair flight to suit available bearings.



Integral landings can be either at top or bottom of stair flight or both top and bottom.

Details to satisfy disproportionate collapse requirements can be provided upon consultation with our design team.



Hillhouse Precast provide a full design service which includes the preparation of layout drawings and design calculations, through to site installation.



All stairs and landings are manufactured and designed in accordance with the relevant standards and codes to suit loadings provided



Our stairs and landings provide a standard 1 hour fire rating, however this can be increased if required.
